AMD Radeon RX 7500 XT
- Graphics Processor
- Navi 33
- Cores
- 1024
- TMUs
- 64
- ROPs
- 32
- Memory Size
- 6 GB
- Memory Type
- GDDR6
- Bus Width
- 96 bit
GPU
Recommended Gaming Resolutions:
- 1920x1080
- 2560x1440
- 3840x2160
The Radeon RX 7500 XT is a graphics card by AMD, that was never released. Built on the 6 nm process, and based on the Navi 33 graphics processor, in its Navi 33 variant, the card supports DirectX 12 Ultimate. This ensures that all modern games will run on Radeon RX 7500 XT. Additionally, the DirectX 12 Ultimate capability guarantees support for hardware-raytracing, variable-rate shading and more, in upcoming video games. The Navi 33 graphics processor is an average sized chip with a die area of 204 mm² and 13,300 million transistors. Unlike the fully unlocked Radeon RX 7600, which uses the same GPU but has all 2048 shaders enabled, AMD has disabled some shading units on the Radeon RX 7500 XT to reach the product's target shader count. It features 1024 shading units, 64 texture mapping units, and 32 ROPs. The card also has 16 raytracing acceleration cores. AMD has paired 6 GB GDDR6 memory with the Radeon RX 7500 XT, which are connected using a 96-bit memory interface. The GPU is operating at a frequency of 1452 MHz, which can be boosted up to 2300 MHz, memory is running at 2250 MHz (18 Gbps effective).
Being a dual-slot card, the AMD Radeon RX 7500 XT draws power from 1x 6-pin power connector, with power draw rated at 100 W maximum. Display outputs include: 1x HDMI 2.1a, 2x DisplayPort 2.1, 1x USB Type-C. Radeon RX 7500 XT is connected to the rest of the system using a PCI-Express 4.0 x8 interface.
Being a dual-slot card, the AMD Radeon RX 7500 XT draws power from 1x 6-pin power connector, with power draw rated at 100 W maximum. Display outputs include: 1x HDMI 2.1a, 2x DisplayPort 2.1, 1x USB Type-C. Radeon RX 7500 XT is connected to the rest of the system using a PCI-Express 4.0 x8 interface.
Graphics Processor
Graphics Card
Relative Performance
Based on TPU review data: "Performance Summary" at 1920x1080, 4K for 2080 Ti and faster.
Performance estimated based on architecture, shader count and clocks.
Clock Speeds
- Base Clock
- 1452 MHz
- Game Clock
- 2200 MHz
- Boost Clock
- 2300 MHz
- Memory Clock
-
2250 MHz
18 Gbps effective
Memory
- Memory Size
- 6 GB
- Memory Type
- GDDR6
- Memory Bus
- 96 bit
- Bandwidth
- 216.0 GB/s
Render Config
- Shading Units
- 1024
- TMUs
- 64
- ROPs
- 32
- Compute Units
- 16
- RT Cores
- 16
- L0 Cache
- 32 KB per WGP
- L1 Cache
- 128 KB per Array
- L2 Cache
- 2 MB
- L3 Cache
- 64 MB
Theoretical Performance
- Pixel Rate
- 73.60 GPixel/s
- Texture Rate
- 147.2 GTexel/s
- FP16 (half)
- 18.84 TFLOPS (2:1)
- FP32 (float)
- 9.421 TFLOPS
- FP64 (double)
- 294.4 GFLOPS (1:32)
Board Design
- Slot Width
- Dual-slot
- TDP
- 100 W
- Suggested PSU
- 300 W
- Outputs
- 1x HDMI 2.1a
2x DisplayPort 2.1
1x USB Type-C
- Power Connectors
- 1x 6-pin
Graphics Features
- DirectX
- 12 Ultimate (12_2)
- OpenGL
- 4.6
- OpenCL
- 2.2
- Vulkan
- 1.3
- Shader Model
- 6.8
Card Notes
| Based on sources online. |
Navi 33 GPU Notes
| Generation: Navi III Codename: Hotpink Bonefish Ray Tracing Cores: 2nd Gen Infinity Cache: 2nd Gen Graphics/Compute: 11.0.2 Shader ISA: GFX11.0 (gfx1102) Display Core Next: 3.2.1 Video Core Next: 4.0.4 System DMA: 6.0.2 Per SIMD32: - 10 KB Scalar Register File Per CU: - 16 KB Vector Data Cache - 64 KB Local Data Share (GCN-Mode) Per WGP: - 16 KB Scalar Data Cache / K Cache - 32 KB Instruction Cache - 128 KB Local Data Share |
